TECHNICAL SPECIFICATIONS:
| Sr. No | Model | Output Kg/Hr |
Mesh Dia (mm) | Screen Mesh Dia (mm) |
Cartridge Heater Voltage (V) |
Heating Load (kW) |
Hyd. Power Pack Motor Detail(HP) |
|---|---|---|---|---|---|---|---|
| 1 | VPH-50 | 50 to 90 | ⌀60 | 2826 | 230/415 | 1.2 | 3.0 |
| 2 | VPH-65 | 75 to 150 | ⌀85 | 5672 | 230/415 | 1.6 | 3.0 |
| 3 | VPH-75 | 125 to 200 | ⌀85 | 5672 | 230/415 | 1.6 | 3.0 |
| 4 | VPH-90 | 160 to 250 | ⌀95 | 7085 | 230/415 | 3.2/4.0 | 3.0 |
| 5 | VPH-100 | 200 to 350 | ⌀103 | 8328 | 230/415 | 4.0 | 3.0 |
| 6 | VPH-110 | 200 to 375 | ⌀110 | 9498 | 230/415 | 4.8 | 3.0 |
| 7 | VPH-120 | 250 to 400 | ⌀125 | 12265 | 230/415 | 6.4/8.0 | 5.0 |
Applications:
Tap Plant ,Pipe Plant, Lamination Plant, Sheet Plant, Film Plant, Blown Film Plant Co-Extrusion line, Blown Moulding Extrusion Plant
Advantages:
• Easy to Operate Frequently During the Operation of Screen Changing.
• High Production Rate increases due to time Saved for Station Changing.
• Easily Capable of handling heavy Volume of Plastic Material
– Safe Operation
• Fully Guarded & Electronically inter locked
• Tempretur Proof Painted On machine
Key Features:
- Hydraulic Operation:
- Equipped with a sophisticated hydraulic system for quick and smooth screen changes.
- Minimizes manual labor, enhancing safety and efficiency in operations.
- Plate Type Design:
- Innovative plate design offers easy access for maintenance and screen replacement.
- Space-saving and robust construction suitable for a variety of industrial settings.
- Continuous Production:
- Enables ongoing production without stopping for screen changes, perfect for high-output environments.
- Maintains consistent extrusion pressure and quality throughout the process.
- High-Quality Filtration:
- Ensures the effective removal of contaminants, resulting in superior product quality.
- Capable of handling a wide range of materials, including various polymers and plastics.
- Durable and Reliable:
- Constructed from high-grade materials to endure harsh industrial conditions.
- Designed for long-term reliability, minimizing the need for frequent maintenance.
- Easy Integration:
- Compatible with various extrusion lines and easy to install.
- Streamlined integration process ensures quick setup and minimal disruption to existing operations.
